XtendLan CAT6 HDMI extender transmitter+receiver 40m 4k 2k 1080p over one CAT6 cable POC IR transmission
XTENDLAN Consumer | EHDMI11EIR4K-TR40 | 6955361274314
On stock 14 pcs.
Price of goods is 54,47 €.
Price without tax is 45,02 €.
VAT rate for CZE 🇨🇿 is 21%.
Weight of goods is 0.46 Kg.
Actual in cart 0 pcs.
XtendLan EHDMI11EIR4K-TR40
With this extender, you can easily transmit an HDMI signal up to 40 m away. The converter (transmitter) converts a standard HDMI signal to a network LAN and uses a CAT6/6a/7 cable to transmit it to the destination, where it is converted back to HDMI. This allows you to transmit images with a resolution of up to 4K safely and without loss of quality. The converters can be controlled remotely using an IR remote control.
- HDMI 1.4 signal transmission
- 4K at 30 Hz transmission at a distance of 40 m and Full HD at 60 Hz at a distance of up to 70 m
- HDCP 1.4, HDR support
- DTS, DTS-HD, PCM, LPCM audio support
- IR pass-back support (20-60 kHz)
- ESD protection, 4 kV contact, 8 kV air, IEC61000-4-2
Supported resolution: up to 4K
Connectors
- 1× HDMI input
- 1× HDMI output
- 1× IR input
- 1× IR output
- 1× RJ-45 input
- 1× RJ-45 output
Transmission technology: via LAN cable
Maximum transmission distance: up to 70 m when using CAT6/6a/7 cable (40 m at 4K)
Dimensions: 75 × 60 × 16.5mm
Weight: 127g
| Name | Value | |
|---|---|---|
| IR transmission | Yes | |
| USB transfer | No | |
| HDMI resolution | 8 Mpx (4K) | |
| Transfer medium | UTP CABLE (DIRECT MODULATION) | |
| Connector 2 | RJ-45 | |
| Transmission type | NO COMPRESSION (NO DELAY) | |
| Connector 1 | HDMI | |
| Color | black | |
| Weight, brutto [kg] | 0,127 | |
