TP-Link TL-SG3428XF JetStream 24-Port SFP L2+ Managed Switch 20x SFP + 4x SFP GLAN Combo 4x 10Gbit SFP+

TP-Link TL-SG3428XF

JetStream managed L2+ switch with 20 SFP slots, 4 combo ports (SFP/RJ-45) and 4 10GE SFP+ slots

High-speed L2+ switch with management and four SFP+ slots for uplink. The capacity of the switch is 128 Gbps and the routing speed is up to 95.23 Mpps. Ideal for the aggregation layer of the network. Security features include IP-MAC-Port-VID binding, port security, Storm Control, and DHCP Snooping to protect against a variety of network threats. The device has an integrated list of typical DoS attacks, making it easier than ever to protect against them. The access control function (ACL, L2 to L4) then also restricts access to sensitive parts of the network by rejecting packets based on source and destination MAC address, IP address, TCP/UDP ports or VLAN ID. User access to the network can be controlled using 802.1X authentication that works with a RADIUS/Tacacs+ server to grant access only to users with valid credentials.

• Lightning 10G Outbound Connection: 4 10Gbit/s SFP+ slots enable high-throughput broadband and non-blocking switching capacity.
• Gigabit speeds: 20 gigabit SFP ports and 4 gigabit combined SFP/RJ45 ports offer high-speed and reliable connections with other switches and devices.

Integrated into the Omada SDN platform

• ZTP (Zero-Touch Provisioning) function
• centralized cloud management and intelligent monitoring.í.
• Centralized management: Cloud access and Omada application for maximum convenience and easy management.

Static routing

• It helps to route the flow of data over the local network
• thereby ensuring the efficient use of network resources.

Robust security strategy

• IP-MAC address binding function
• ACL
• port security
• protection against DoS attacks
• Storm Control function
• DHCP Snooping function
• 802.1X and Radius protocol authentication and other functions.e.
• Optimized voice and video transmission in applications: L2/L3/L4 QoS and IGMP Snooping function.

Separate administration

• Web interface
• CLI (console port
• Telnet
• SSH)
• SNMP
• RMON and the Dual Image function bring advanced management options.y.

Ports

• 20x Gbit SFP slot
• 4x combo port (SFP/RJ-45)
• 4x 10Gbit SFP+ slot
• 1x RJ-45 console port
• 1x microUSB console por

Switch capacity: 128 Gbps

Routing Speed: 95.23 Mpps

PoE: no

Max. power consumption: 35.7 W

Dimensions: 440 x 220 x 44 mm
