Planet POE-1200G(v2) PoE injector 12x 1Gb 802.3at 30 220W PING watchdog+scheduler

PLANET POE-1200G

12-port PoE injector for 10/100/1000Base-T Ethernet power supply. Standard 802.3at, Mid-span. 12 data-in ports, 12 data+power out ports. Total power 220W, 30W/port. Web management, status monitoring and port power control, "Power Scheduler" - time scheduler, PING watchdog. Hardware version 4.

12-port gigabit PoE injector with full support for IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af and IEEE 802.3at standards. The device powers end-powered devices (PD-powered devices) 52V DC with a total load capacity of 220W. It is installed between a classic Ethernet switch and powered devices, thereby associating the voltage for the operation of end devices on the Ethernet line without effect on the data transfer speed or the limit on the maximum distance of the connection segment (ethernet up to 100m). The POE-1200G is a solution for powering 802.3af/at compatible devices without the need to install additional cabling or power supplies. This allows the existing network topology to be preserved.

The web management of the device offers the user the possibility to control the injector and, therefore, the terminal powered devices, it has functions for timed switching on (scheduler), detection of device operation based on PING and the subsequent possibility to restart the device.

Interface

• 24 x RJ-45 10/100/1000 Mbps : 12 x Data input
• 12 x PoE (Data + Power) outputs

Total power output

• up to 220 W
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab
• IEEE 802.3at

Port load capacity: up to 60 W

Power supply

• 100-240V AC
• 50/60 Hz
• 8A

Operating temperature: 0 to 50°C

Dimensions: 440 x 300 x 44.5 mm

Weight: 4.8 kg
