ARCTIC P12 Pro 120mm fan

ARCTIC P12 Pro - cooling with minimal noise

ARCTIC P12 Pro fan, which will not get tired in a work, multimedia or gaming PC setup. It is designed for long-term and efficient operation, which will keep your computer components at optimal operating temperatures. ARCTIC P12 Pro fan with continuous speed control achieves high static pressure, which makes it a perfect complement to the functions of perforated panels and other types of cases.

Improved fan blade design supports smooth and stable air flow. It also includes a modern fluid dynamic bearing, which contributes to quiet operation and ensures long service life.

ARCTIC P12 Pro

Powerful 120mm PWM fan with stepless speed control for maximum cooling and minimal noise

ARCTIC P12 Pro is a premium 120mm fan designed for high static pressure, which ensures optimal airflow even in areas with limited airflow, such as CPU coolers or radiators. Thanks to PWM control in the range of 600-3000 RPM, it offers flexible power settings according to current cooling needs.

The fan uses a modern fluid dynamic bearing, which guarantees quiet operation and long service life. With an airflow of 131 m3/h and a static pressure of 6.9 mmH2O, it provides excellent cooling performance for demanding applications.

• Continuous PWM speed control in the range of 600-3000 RPM with the possibility of complete stop at PWM signal below 5%
• High static pressure 6.9 mmH2O ideal for cooling radiators and CPU coolers
• Air flow of 77 CFM (131 m3/h) ensures effective cooling of components
• Fluid dynamic bearing for quiet operation and extended service life
• Low starting voltage of 3.3 V DC allows reliable start-up even at low speeds
• Standard 4-pin PWM connector for precise fan speed control
• Compact dimensions of 120 × 120 × 25 mm with a weight of only 183 g
• Operating temperature 0-40 °C for a wide range of applications

Precise PWM control

Thanks to the PWM characteristic, you can continuously regulate the fan speed from 600 to 3000 RPM. At a PWM signal lower than 5%, the fan stops completely, allowing for absolutely silent operation in idle mode.

Optimized blade design

Specially designed fan blades maximize static pressure while maintaining high airflow, an ideal combination for cooling radiators, CPU coolers, and other components with limited airflow.

Easy installation

Four mounting screws are included for easy installation of the fan in a computer case or on a radiator. The 400mm cable provides sufficient flexibility for installation.

Dimensions: 120 × 120 × 25 mm

Weight: 183 g

Speed

• 600-3000 RPM
• 0 RPM below 5% PWM

Airflow

• 77 CFM
• 131 m3/h

Static pressure: 6.9 mmH2O

Bearing type: FDB (fluid dynamic bearing)

Power supply voltage: 12 V DC

Start voltage: 3.3 V DC

Current: 0.33 A

Cable length: 400 mm

Connector: 4pin PWM

Operating temperature: 0-40 °C

Package contents

• P12 For fan
• 4× mounting screws
